KVAC Vacuum Oil
Model:KVO100|KVO120|KVO200|KVO400
Category:Vacuum Pump Spare Parts

KVO100

Application:

Formulated from high-quality base oils and specially designed high-performance additives, it provides lubrication and protection for single-stage rotary vane pumps and roots pumps.

Ideal for operating conditions where the outlet temperature is below 100°C; synthetic lubricants are recommended for higher temperatures.


Advantage:

Excellent oxidation resistance

Prevents carbon deposit formation

Excellent oil/gas and oil/condensate separation performance

Protects rotor chambers from wear and corrosion

Superior anti-clogging performance to maintain filter efficiency over extended periods


Specification:

ModelDensity (20°C)Kinematic Viscosity (40°C)Viscosity IndexPour PointFlash Point (Open Cup) Residue-conradson
UNITkg/m³mm²/s-°C°C%
MethodASTM D1298ASTM D445ASTM D2770ASTM D97ASTM D92NFT 60116
KVO10086968.8108-332380.1


KVO120

Application:

KVO120 high vacuum oil is suitable for demanding operating conditions, maintaining excellent vacuum performance even under high temperature, high pressure, or high load conditions.

It can be used with various domestic mechanical vacuum pumps, including two-stage oil-sealed rotary vane pumps from brands such as Edwards (UK) and Leybold (Germany).


Performance:

KVO120 high vacuum oil offers a wider operating temperature range than KVO100.

Significantly improved anti-wear performance to reduce interface wear during pump compression.

Excellent oxidation stability, reducing the frequency of oil changes.

Excellent foam characteristics to minimize pump wear caused by overflow or flow interruption.

KVO120 high vacuum pump oil significantly extends pump service life and ensures long-term high-vacuum operation.


Specification:

ModelOxidation Stability @150°C

Kinematic Viscosity

 (40°C)

Viscosity IndexPour Point

Flash Point

 (Open Cup)

Demulsibility

 (40-40-0) ml

Foam Characteristics (ml/ml)

 (Foam Tendency/Stability)

Extreme Pressure
UNITminmm²/s-°C°Cmin-Kpü
MethodSH/T0193GB/T265GB/T2541GB/T3535GB/T3536GB/T7305GB/T12579GB/T6306.2
KVO12086990-110110-1525010 at 82°C ≤50/02*10^-5 at partial pressure
2*10^-4 at full pressure


KVO200

Advantage:

Fewer oil changes required

Reduces compressor maintenance

Significantly reduces fire and explosion risks

Rapid condensate water separation

Low oil consumption

Eliminates varnish and deposits

Energy efficient


Specification:

ModelViscosity @40°CViscosity @100°CSpecific Gravity (15.6°C)Pour Point

Flash Point

 (Open Cup)

Autoignition Temperature
UNITmm²/smm²/s-°C°C°C
MethodASTM D445ASTM D445ASTM D-4052BASTM D97ASTM D92ASTM E-659
KVO200979.30.996-35274410
ModelConradson Carbon Residue

Evaporation Rate

 (22 hrs @99°C)

Copper Strip Corrosion

 (3 hrs @100°C)

Demulsibility @54°C

 (ml oil/ml water/mls, min)



UNIT%%--ml

MethodASTM D189ASTM D972ASTM D130ASTM D1401

KVO2000.02<1.01a39/38/3(<60)


KVO400

Application:

KVO400 is a high vacuum grease formulated from a special low-vapor-pressure oil, ideal for high-vacuum applications.

It can also be used to seal connections in laboratory glassware and as a thread lubricant/sealant.


Performance:

KVO400 vacuum pump oil is used in applications where traditional vacuum pump oils pose safety, waste disposal, and maintenance issues. They are non-flammable, eliminating the risk of pump fires. They are non-reactive and safe for use in oxygen systems. They can replace competitors' PFPE fluids and any other type of vacuum fluid. KVO400 fluids do not contain acetal groups vulnerable to attack by Lewis acids. KVO400 exhibits excellent stability as a vacuum pump fluid. Krytox® vacuum fluids are precisely distilled to provide low vapor pressure and superior performance. Additionally, KVO400 fluids are recyclable.

KVO400 oil contains soluble additives to prevent rust. This patented additive enhances the performance of KVO fluids, providing improved long-term rust protection against moisture and additional corrosion protection for metal components and bearing surfaces.

While KVO fluids are inert and non-reactive with all elastomers, plastics, and metals, the soluble additives in XP products have not been tested on all materials. Initial testing shows no issues with DuPont Teflon®, Kalrez®, Viton®, nitrile rubber, and silicone rubber. The performance of soluble additives may degrade over extended periods at temperatures exceeding 182°C (360°F).


Specification:

ModelAverage Molecular WeightVapor Pressure*Kinematic ViscosityPour PointDensityHeat of Vaporization
UNITminTORRmm²/s°Cg/cccal/g
MethodNMRKnudsenASTM D445ASTM D97
Knudsen
KVO40034701*10^-7 at 20°C250 at 20°C-481.9 at 20°C6
ModelDistillationVolatility (22 hrs)Surface Tension


UNIT°C%dyn/cm


MethodASTM D1160ASTM D2595



KVO400200 at 10%0.619 at 25°C
